1、Quad-core professional processor-ARM Cortex-A55
2、8Gb/DDR4 large memory for masses of applications，
3、6-inch high-definition touch screen, more concise and rich UI interface
4、Wi-Fi 6 wireless network
5、M.2 Nvme 3.0 SSD (not included), up to 4TB
6、Professional DSP Upsamplin processing, Convert DSD and PCM formats to each other
7、Signal & noise isolation technology, isolates EMI interference between digital circuits and analog circuits,
8、Dual power supply design (low noise linear power supply + switching power supply module), independent power supply system for analog and digital parts
9、Self-developed ultra-low noise LDO voltage regulator, noise≤0.6μVrms(10Hz-100kHz）(LT3045 /0.8μVRMS)
10、NDK low phase noise dual Femto Clock (45.1582MHz/49.152MHz)，reduced clock jitter
11、The 3rd USB interface XMOS-XU316，support PCM768/Native DSD512/MQA hardware decoding
12、USB, Optical, Coaxial, I2S digital output Bit-perfect (without DAC)
13、Dual CS43198 chips decoding , fully balanced different
2、8Gb/DDR4 large memory for masses of applications，
3、6-inch high-definition touch screen, more concise and rich UI interface
4、Wi-Fi 6 wireless network
5、M.2 Nvme 3.0 SSD (not included), up to 4TB
6、Professional DSP Upsamplin processing, Convert DSD and PCM formats to each other
7、Signal & noise isolation technology, isolates EMI interference between digital circuits and analog circuits,
8、Dual power supply design (low noise linear power supply + switching power supply module), independent power supply system for analog and digital parts
9、Self-developed ultra-low noise LDO voltage regulator, noise≤0.6μVrms(10Hz-100kHz）(LT3045 /0.8μVRMS)
10、NDK low phase noise dual Femto Clock (45.1582MHz/49.152MHz)，reduced clock jitter
11、The 3rd USB interface XMOS-XU316，support PCM768/Native DSD512/MQA hardware decoding
12、USB, Optical, Coaxial, I2S digital output Bit-perfect (without DAC)
13、Dual CS43198 chips decoding , fully balanced different
OVERVIEWTECH SPECSMANUALS
Models | MX-5(without DAC) | MX-5S All in one | MX-5S Pro All in one | |
| OS | Android 12 | |||
| CPU | 4 core /2.0 G A55 | |||
| DDR | 4GB /8GB (Optional) | |||
| Display | 6-Inch touch screen | |||
| Wireless network | Wi-Fi 6 | |||
| Wired network | 100/1000Mbps | |||
| Built-in HDD socket | M.2 Nvme SSD/ 4TB | |||
| USB HDD socket | USB3.0/ 10TB | |||
Network Protocol | DLNA | Supported | ||
| AirPlay | Supported | |||
| Samba | Supported | |||
| Baidu disk | Supported | |||
| OneDrive | Supported | |||
Digital Input | USB | DSD512(Native) / PCM32Bit/384KHz | ||
| I2S | DSD512(Native) / PCM32Bit/384KHz | |||
| Coaxial | 24Bit/192KHz/ DoP64 | |||
| Optical | 24Bit/192KHz/ DoP64 | |||
| Bluetooth 5.1 | QCC5125 apt X -HD +LDAC | |||
Digital Output | USB | DSD512(Native) / PCM32Bit/384KHz | ||
I2S | DSD512(Native) PCM32Bit/384KHz | DSD512(Native) PCM32Bit/384KHz | ||
| Coaxial | 24Bit/192KHz/DoP | 24Bit/192KHz/DoP | ||
| Optical | 24Bit/192KHz/DoP | 24Bit/192KHz/DoP | ||
| Bluetooth 5.0 | 24Bit/48KHz | |||
| HDMI | Supported | |||
| Audio clock | Dual Femto Clock (45.1584MHz/49.152MHz) | |||
| DSP Upsampling | Supported | |||
| DAC Chips | 2*CS43198 | 2*AKM4499+4191 | ||
| Power supplyAC 110~240V 50/60Hz | Linear power supply | Dual power supply | Dual power supply | |
| Dimensions | 305*220*85mm | 305*220*85mm | 430*300*85mm | |
